In the demanding cable and wire industry, producing consistent, high-quality compounds for PVC insulation/sheathing, low-smoke halogen-free (LSZH/HFFR), 10–35 kV chemically cross-linked PE (XLPE), and semi-conductive shielding materials requires exceptional mixing uniformity, precise temperature control, and outstanding energy efficiency. The RLB Two Stage Reciprocating & Single Screw Pelletizing Line (also known as the reciprocating kneader + single-screw tandem pelletizing unit) is specifically engineered to meet these challenges while delivering up to 25 % energy savings compared to conventional extruders.
This advanced two-stage system combines a high-intensity reciprocating single-screw mixer (first stage) with a low-shear single-screw extruder (second stage) connected via T-type distribution. The reciprocating motion provides powerful radial and axial mixing, short material residence time, high filler loading capacity, and superior self-cleaning performance — ensuring uniform dispersion without temperature peaks that could degrade sensitive polymers.
Key Engineering Advantages
- Superior Mixing Performance: Both radial and axial mixing action plus excellent injection of liquid additives deliver homogeneous compounds with minimal shear heat.
- Energy-Efficient Design: Proven 25 % lower power consumption than standard extruders while maintaining high throughput.
- Hassas Sıcaklık Kontrolü: No melting temperature peaks — critical for heat-sensitive materials like LSZH and XLPE.
- High Filling Capacity & Quick Changeover: Excellent self-cleaning properties and short conversion time maximize equipment utilization and reduce downtime.
- Fully Automated System: Gravimetric weighing for granules/powders, forced feeding, and precise liquid dosing combined with MMI + PLC control for recipe storage, real-time monitoring, and simple operation.
- Flexible Downstream Options: Water-ring cutting, eccentric water-mist cutting, plus various packaging solutions (bin collecting, ton-bag, automatic weighing & bagging).
The result is high-quality, dust-free pellets with excellent flow characteristics and consistent physical properties — exactly what cable manufacturers need for high-voltage, flame-retardant, and specialty applications.
Technical Specifications (RLB Two Stage Reciprocating & Single Screw Pelletizing Line)
| Model |
Reciprocating Screw Dia. (mm) |
Reciprocating Screw Speed (rpm) |
Reciprocating L/D |
Reciprocating Motor Power (kW) |
Output (kg/h) |
Single Screw Dia. (mm) |
Single Screw Speed (rpm) |
Single L/D |
Single Motor Power (kW) |
| RLB-140/200 |
140 |
250/400 |
15 |
160–200 |
1000–1300 |
200 |
65/85 |
7–10 |
75 |
| RLB-58/100 |
58 |
400/500 |
15 |
30–45 |
100–200 |
100 |
65/85 |
7–10 |
37 |
| RLB-85/180 |
85 |
400/500 |
15 |
160–200 |
800–1500 |
180 |
65/85 |
7–10 |
55–75 |
| RLB-120/220 |
120 |
400/500 |
15 |
280–400 |
1800–3000 |
220 |
65/85 |
7–10 |
90–110 |
Higher-capacity custom models available upon request.
Başlıca Uygulamalar
- PVC cable compounds (insulation and sheathing)
- Low-smoke halogen-free (LSZH / HFFR) cable materials
- 10–35 kV chemically cross-linked PE (XLPE) compounds
- Semi-conductive shielding compounds
- Other high-filler or reactive cable-grade compounds
The RLB reciprocating two-stage pelletizing line is the ideal choice for cable manufacturers seeking higher output, lower energy costs, superior compound quality, and rapid product changeovers.
Engineered for Reliability, Efficiency & Long-Term ROI
Üretici firma: RLB (Jiangsu Güvenilir Endüstri A.Ş., Ltd.) — a trusted cable and wire machinery supplier — every component of this Two Stage Reciprocating & Single Screw Pelletizing Line is built for 24/7 continuous operation with minimal maintenance. Compared to conventional single-screw or twin-screw systems, the RLB reciprocating design offers:
- Up to 25% energy savings
- Superior filler dispersion and homogeneity
- No thermal degradation of sensitive materials
- Significantly reduced scrap and faster grade changeovers
Whether you produce standard PVC compounds or premium LSZH/XLPE materials for high-voltage cables, this cable compound pelletizing line delivers the performance, flexibility, and long-term reliability modern compound producers demand.
Ready to optimize your cable compound production with 25% energy savings?
Şimdi bilgi isteyin for technical quotation, custom configuration, layout design, or factory visit. Our engineering team provides full turnkey solutions, installation support, operator training, and ongoing technical partnership.
